Wheel loader with 800 kg nominal load (HZC809)

15.790.00

Includes 19% MwSt.
Available as pre-order in approximately 45-60 days.
Delivery Time: approx. 10 workdays

  • Total weight: 2430 kg
  • Maximum tractive force: 37 kN
  • Maximum dumping height: 2400 mm
  • Maximum tipping range: 600 mm
  • Overall dimensions: 4600x1660x2630 mm

Available on backorder

+ -
Select delivery location

Wheel loader with 800 kg nominal load (HZC809)

The HZC809 wheel loader from HZC Power is a rather small wheel loader and therefore particularly flexible and manoeuvrable. It is a versatile helper on construction sites of various sizes, in the yard or in gardening and landscaping. Due to its high-quality workmanship, simple operation, the compact wheel loader is a perfect machine for professional use.

The HZC809 from HZC Power combines power with flexibility. The compact design with dimensions of 4600x1660x2630 mm make the wheel loader a flexible helper on your construction site. The diesel engine convinces with its usual high quality and reliability. The maximum gradeability of the wheel loader is 35° and the maximum tractive force is 38 kN.

HZC809_8

Drive

The HZC809 from HZC Power combines power with flexibility. The compact design with dimensions of 4600x1660x2630 mm make the wheel loader a flexible helper on your construction site. The diesel engine convinces with its usual high quality and reliability. The maximum gradeability of the wheel loader is 35° and the maximum tractive force is 38 kN.

Equipament

The wheel loader is equipped with a bucket as standard. The nominal capacity of the bucket is 0.5m3. The wheel loader has 2 forward and reverse gears each and reaches a maximum speed of 25 km/h.

Offer for your HZC Power product

At HZC Power we always pay attention to the highest quality, technically flawless processing and robust construction. You will receive our products partially assembled by freight forwarding. We offer you a fixed price for shipping which is automatically generated in the shopping cart (additional shipping information can be found here).

You are welcome to visit our products by appointment at our headquarters (Krefeld, NRW) or at our location near Berlin (14542 Werder) or pick them up free of charge.

If you have further questions about the individual models then please contact our customer service. This advises you gladly further. Convince yourself of our offer and secure your product in the best quality at the best price at HZC Power.

DKB981 (48)

Technical data performance

Nominal load: 800 kg
Total weight: 2430 kg
Nominal bucket capacity: 0.5 m3
Maximum tractive force: 37 kN
Maximum breakout force: ≥ 38 kN
Maximum gradient: 35
Maximum dumping height : 2400 mm
Maximum tipping reach : 600 mm
Overall dimensions: 4600×1660×2630 mm
Minimum turning radius: 4500 mm

Engine

Engine manufacturer: YunNei diesel engine (YN27)
Type: Inline water cooling, dry cylinder injection
Number of cylinders – bore -stroke: 4-90×105 mm
Rated power: 42 KW – 2400 r/min
Maximum torque: 210 Nm
Minimum fuel consumption ratio: ≤ 225 g/kw.h

Transmission system

Gearbox: powershift transmission
Gear change: 2 forward gears, 2 reverse gears
Maximum speed: 25 km/h
Wheelbase: 1850 mm
Wheel tread: 1280 mm
Minimum ground clearance: 220 mm

Hydraulic system

Operating pressure of the system: 16 MPa
Bucket lifting time: ≤ 4.7 s
Bucket drop time: ≤ 3.2 s
Total time for a single work cycle: ≤ 9 s

Brake system

Service brake: drum brake
Parking brake: manual parking brake

Tires

Type specification: 31×15.5-15
Front tyre pressure: 0.35 MPa
Rear tyre pressure: 0.35 MPa

Features

4 additional hydraulic lines
Quick change system for bucket
Electric joystick
Reversing camera
Adjustable steering wheel
Front windscreen heating
