20 t horizontal wood splitter with petrol engine (HS20203)

20 t horizontal wood splitter with petrol engine (HS20203)

Reference: HS20203

€1,259.00
Tax included excl. Shipping Delivery Time: 45-60 days
  • 20 t splitting force
  • Oil filter for a longer service life
  • Trailer coupling
  • Easy handling
  • High quality and robust workmanship
Quantity
45-60 days



Secure payment & privacy



Own workshop for repair & maintenance



Locally test drive demonstration

Calculate Delivery Cost

With the HS20203 from HZC Power you can split logs up to 600 mm long with a splitting force of up to 20 tonnes. The two-hand operation ensures safety. Nevertheless, the operation is practical and simple.


Drive

The log splitter is equipped with a powerful Briggs&Stratton petrol engine (6.5 HP, XR950). The engine is equipped with 12,88 Nm gross torque and 208cc. Briggs&Stratton's maintenance/repair service in selected partner garages provides uncomplicated assistance should problems arise with the powerful engine.

Briggs&Stratton Logo


Equipment

With a horizontal log splitter - like the HS20203 - the splitting material is placed on a horizontal splitting table. The splitting material is pressed horizontally by the pressure plate into the sharp splitting wedge and thus split. The length of the splitting material is usually very suitable for the chimney or a fireplace. The splitter has a trailer coupling so that it can easily be moved around in the yard. However, the HS20203 is not road legal. Due to the handy dimensions of 226,5x101x118,5 cm (LxWxH) the log splitter can be easily transported on a trailer.


At HZC Power, we always ensure the highest quality, technically perfect workmanship and robust construction. Our log splitters are available partially assembled by a forwarding agent. It may be necessary to top up the hydraulic oil - we supply this with the splitter! We offer you a fixed price for shipping which is automatically generated in the shopping cart (additional shipping information can be found here).

You are welcome to visit our wood splitters on site (Krefeld, NRW) or pick them up free of charge. If you have further questions about the individual models, please contact our customer service. They will be happy to advise you further. Convince yourself of our offer and get your best quality wood splitter at the best price at HZC Power.


Technical data

Manufacturer: HZC Power
Model: HS20203
Splitting force: 20 t
Gap length: max. 570 mm
Cycle: 13 s
Hydraulic oil capacity: 14L (HLP46)
Product weight: 203 kg
Shipping weight: 218 kg
Product dimensions: 207,5x101x115,5 cm (lxwxh)
Special features: trailer coupling
Working positions: Horizontal
Operation: 2-handed

Engine

Engine: Briggs & Stratton 6.5 hp petrol engine, XR950
Model number: 130G
Engine technology: Single cylinder, 4-stroke, air-cooled, OHV (overhead valves)
Displacement: 208 cc
Cylinder: cylinder with cast iron sleeve
Drill hole: 68,3 mm
Bar: 55,9 mm
Fuel tank capacity: 3.1 l
Oil capacity: 0.6 l
Weight: 16 kg
Dimensions (WxLxH): 321x376x346 mm

HS20203

Data sheet

Type of splitter
Horizontal
Drive
Petrol
Splitting force
20 t
Slit length
570 mm
